American Diagnostic Corporation ADSTATION Coax XENON 3.5V Ophthalmoscope, 120V Wall Transformer & XENON 3.5V Throat Illuminator
: 19960082
Start with as little as a single instrument wall transformer and expand with up to 3 more connected extension modules • Diagnostix Coax XENON 3.5V Ophthalmoscope Instrument Head 5440 • 120V Wall Transformer 5660T • Diagnostix XENON 3.5V Throat Illuminator Instrument Head 5426 • UL Approved • 5 year warranty on wall transformer and extension modules • Lifetime warranty on LED lamps
• Diagnostix Coax XENON 3.5V Ophthalmoscope Instrument Head 5440 •High performance aspherical condenser lens
reduces corneal reflection
• Ergonomic design and integral thumb rest improves
stability and allows one finger control of all functions
• Synthetic rubber brow rest facilitates use with
practitioner eyeglasses
• Dust proof
• Magnified/illuminated aperture viewing window
• Instrument head uses universal bayonet
mount for compatibility with other brands of
3.5 volt power supply handles
• Anti-theft locking feature is standard
• XENON illumination
• 2 year warranty on instrument
• 29 viewing lenses from -35 to +40 (Plus)
1-10, 12, 15, 20, 40 – (Minus) 1-10, 15, 20,
25, 30, 35)
• 24 aperture/filter combinations for improved
versatility • 120V Wall Transformer 5660T • Magnetic switch activates power when handle is removed from cradle, automatically powers off when handle is replaced
• Handle CNC machined from solid brass, the handle is chrome plated in black with a ribbed surface for a sure grip
• Adtronic electronic rheostatic light intensity control provides infinite continuous control
• Adtronic auto-off feature after 2 minutes provides additional safety if instrument is mis-cradled
• Bayonet instrument mount is compatible with all major brands of 3.5v instrument heads
• Base unit contains power switch and one handle
• Up to 3 single handle extension units can be added
• Easy to install with included bracket or may be mounted to our wallboard systems
• Available in 120v or 230v power supply with Euro plug
• UL approved
• Five year warranty • Diagnostix XENON 3.5V Throat Illuminator Instrument Head 5426 • PMMA light transmission
• Tongue blade holder facilitates examination
of the mouth and throat
• Manufactured in Germany, inspected and
packaged in the U.S.A.
• Eject button discards used tongue blade
• Works with 5460, 5560, 5660 handles
• 2 year warranty on instrument
